Zig Zag Separators

The Zig Zag Separator works based on weight differences. This highly efficient separator uses airflow to separate materials by weight. The zig-zag design extends the fall path of materials, providing a more homogeneous and accurate separation process. It is ideal for separating materials such as plastics and light metals from metal scraps. Our machine is designed to be integrated into production lines, offering maximum performance with low energy consumption. Additionally, its compact structure allows it to operate with minimal space requirements. The Zig Zag Separator provides an eco-friendly solution with high efficiency and low operating costs, optimizing your recycling process.

Recyclable Materials

Cable
Circuit Board
Radiator
Multi Metal

Technical Specification

  ZZS S1
FEATURE VALUE
TOTAL POWER 11 kW / 14.7 HP
OVERALL LENGTH 2.000 mm / 78.7"
OVERALL WIDTH 1.250 mm / 49.2"
OVERALL HEIGHT 4.000 mm / 157.4"
OVERALL WEIGHT 600 kg / 1,320 lb
  ZZS M1
FEATURE VALUE
TOTAL POWER 17 kW / 22.7 HP
OVERALL LENGTH 2.000 mm / 78.7"
OVERALL WIDTH 1.250 mm / 49.2"
OVERALL HEIGHT 4.180 mm / 164.6"
OVERALL WEIGHT 700 kg / 1,540 lb
  ZZS L1
FEATURE VALUE
TOTAL POWER 30 kW / 40.2 HP
OVERALL LENGTH 2.000 mm / 78.7"
OVERALL WIDTH 1.250 mm / 49.2"
OVERALL HEIGHT 4.300 mm / 169.3"
OVERALL WEIGHT 800 kg / 1,760 lb
